Product Introduction

Overview

VS373 is a Radar Fall Detection Sensor that adopts a Millimeter Wave Radar to detect fall. It enables non-contact human detection using point cloud data and triggers fall alarms. With up to 99% fall detection accuracy, it helps ensure user safety.

With easy configuration and wireless detection, the VS373 supports Wi-Fi communication, enabling high-speed data transmission. It also supports LoRaWAN® communication and can be integrated with the Milesight LoRaWAN® gateway and Milesight Development Platform, enabling remote monitoring, data visualization, and centralized management. As a Milesight D2D controller & agent, the VS373 seamlessly communicates with other Milesight D2D devices, establishing more connections and paving the way for smoother operations. It can also be connected to an alarm switch to notify relevant personnel for emergency response.

VS373 can be used in living rooms, bathrooms, bedrooms, kitchens, hospital wards, care homes, and other spaces where falls may occur.

Key Features

  • Equipped with Millimeter Wave Radar, it can overcome the adverse effects of light and water mist, which make it able to penetrate some obstacles
  • Equipped with a millimeter-wave MIMO array antenna (24 Transmitters & 22 Receivers), it can provide higher precision and reliability
  • Support continuous 24-hour detection and management capabilities, it does not rely on visible light and can operate stably both day and night
  • Support fall detection with a 99% fall capture rate and less than 1% false alarm rate
  • Supports adding sub-regions for independent detection
  • Support multi-bed presence detection, leaving the bed within the scheduling time will trigger an alarm
  • Supports breathing detection by sensing chest movement and providing a reference breathing rate
  • 100% privacy protection, no images will be captured
  • Support on-site alarms of buzzer and LED indicator and provide backend reporting of alarm information, enabling timely notification of any emergency
  • Stores historical data locally and supports retransmission to prevent data loss
  • Supports convenient data transmission via Wi-Fi
  • Compliant with standard LoRaWAN® gateways and network servers
  • Support Milesight D2D protocol to enable ultra-low latency and direct control without gateways
