Hardware Introduction
Packing List
 |
 |
 |
 |
| 1 × VS135 Device | 4 × Ceiling Mounting Kits | 8 × Staff Tags | 1× Power Adapter (Optional) |
|
|
|
|
| 1 × Warranty Card | 1 × Quick Guide | 1 × Multi-interface Cable | 1 × PoE Injector (Optional) |
Note:
- The device supports mounting kits and people counter accessories. For more
information, please scan the QR code.
- If any of the above items is missing or damaged, please contact your sales representative.
Hardware Overview
Dimensions (mm)
Button and LED Indicators
| Function | Action | LED Indication |
|---|---|---|
| Turn On/Off Wi-Fi | Press and hold the power button for more than 3 seconds. | Turn On/Off: Blue light blinks
for 3 seconds. Wi-Fi On: Blue light on. Wi-Fi Off: Green light on. |
| Reset to Factory Default | Press and hold the reset button for more than 10 seconds. | Green light blinks until the reset process is completed. |
Wirings
