Hardware Introduction
Packing List
 |
 |
 |
| 1 × VS133-P Device | 4 × Ceiling Mounting Kits | 8 × Staff Tags |
 |
 |
 |
| 1 × Multi-interface Cable | 1 × Warranty Card | 1 × Quick Guide |
Note:
- The device supports mounting kits and people counter accessories. For more
information, please scan the QR code.
- If any of the above items is missing or damaged, please contact your sales representative.
Hardware Overview
Dimension(mm)
Reset Button
| Function | Action | LED Indication |
|---|---|---|
| Reset to Factory Default | Press and hold the reset button for more than 10 seconds. | Green light blinks until the reset process is completed |
Wiring Diagram
