Overview
Multi-device stitching is mainly used to monitor a larger detection area than just the area covered by a single device. VS125 Series supports stitching up to 16 devices, with both the cellular and PoE versions being compatible for seamless integration, regardless of the version.
When using this feature, devices should be installed next to each other and ensure the
detection areas are tangent or overlapping.
Note:
- The horizontal distance between the two devices must be less than x, and the
vertical distance must be less than y.
x and y indicates the detection range, refer to Covered Detection Area for the calculation formula.
- Ensure most targets near the edges of both devices' views can be fully
captured and detected at the same time.
Before using this feature, set one device as Master Mode and other devices as Node Mode.
- Master Mode: Receive target tracks and view from the device, responsible for all counts, rule setting, data push and other functions.
- Node Mode: Only extends the view of the master device.
