Unlock Enhanced Connectivity, Unleash More Possibilities
HL31
Wi-Fi Halow
Experience the next generation of wireless connectivity option for picture transmission solutions. With the Milesight Wi-Fi Halow product portfolio — HL31 WiFi Halow Gateway and X1 Sensing Camera(Wi-Fi Halow Version), you can unlock the full potential of a connected world.
HL31 stands out for its remarkable ability to effectively handle substantial data throughput while consuming lower power, filling the gap between LoRaWAN® and Wi-Fi, and enabling new IoT solutions enter to the market—a promising picture camera solution delivering together with X1 Sensing Camera(Wi-Fi Halow Version)as an Wi-Fi HaLow client.
HL31 and nodes are transmitted using the Wi-Fi HaLow protocol based on the existing IP protocol stack. The gateway serves as the Wi-Fi HaLow AP to provide the network for the Wi-Fi HaLow Client, eliminating the challenges of network setup and alternative mesh network deployments.
Compared to standard Wi-Fi, the lower frequency bands enable the HL31 to feature improved penetration capability and a wider coverage range—a communication range of up to 1 km under optimal conditions.
Featuring multiple network access and VPN tunnels, HL31 provides secure and reliable solutions for a range of IoT deployments.
Equipped with advanced hardware, the HL31 device offers exceptional performance for data transmission, ensuring stable operation even in versatile indoor environments.
HL31 works with new Milesight management platform.It enables remote device management and gateway data administration, enhancing business productivity and ease of digitalization to the next level.
HL31 enables expanded capabilities for transmitting large data volumes, including images, while preserving low-power requirements. Ideal for small to medium-sized coverage areas such as smart building and smart industry applications.
Smart Building
Smart Industry
Desktop Mounting
Ceiling or Wall Mounting
| Hardware System | |
|---|---|
| CPU | Quad-core 1.3GHz, 64-bit ARM Cortex-A35 |
| Memory | 256 MB DDR3 |
| Flash | 4 GB eMMC |
| Wi-Fi HaLow | |
| Standard | IEEE 802.11ah (1 × 1) |
| Antenna | 1 × External Antenna |
| Channel Bandwidth | 1/2/4/8 MHz |
| Frequency | 850~850 MHz (AU, EU, IN, KR, NZ, SG, US) |
| Data Rate | Up to 32 Mbps |
| Sensitivity | -77.5 ~ -109 dBm |
| Output Power | 21dBm Max |
| Mode | AP Mode |
| Security | WPA3-SAE |
| Cellular Interface (Optional) | |
| Network | 4G LTE (CAT 4)/WCDMA/GSM |
| Antenna | 1 x External Antenna |
| SIM Slots | 1 (Micro SIM-3FF) |
| Ethernet Interface | |
| Port | 1 × RJ45 WAN Port |
| Physical Layer | 10/100 Base-T (IEEE 802.3) |
| Data Rate | 10/100 Mbps (Auto-Sensing) |
| Interface | Auto MDI/MDIX |
| Mode | Full or Half Duplex (Auto-Sensing) |
| Wi-Fi | |
| Standards | IEEE 802.11b/g/n, 2.4 GHz |
| Mode | AP Mode (Device Configuration Only) |
| Others | |
| Button | 1 × Reset Button |
| Console Port | 1 × USB 2.0 (Type-C) for Power Supply and Console |
| LED Indicators | 1 × SYSTEM, 1 x LTE |
| Built-in | Watchdog, Timer |
| Software | |
| Network Protocols | PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, DDNS, HTTP, HTTPS, DNS, ARP, SNTP, Telnet, SSH, etc. |
| VPN Tunnel | OpenVPN/IPsec/PPTP/L2TP/GRE/DMVPN |
| Power Supply and Consumption | |
| Power Input | 1. 5V by Type-C Port 2. 5~12V DC by 3.5mm 2-pin Terminal Block 3. 802.3af standard PoE input by (Optional) PoE Splitter |
| Physical Characteristics | |
| Ingress Protection | IP30 |
| Dimensions | Ф 115 x 21 mm (Ф 4.52 x 0.83 in) (Antenna Excluded) |
| Color & Material | Black, PC + ABS |
| Installation | Desktop, Wall or Ceiling Mounting |
| Environmental | |
| Operating Temperature | -20°C to +50°C (-4℉ to +122℉) |
| Storage Temperature | -40°C to +85°C (-40℉ to +185℉) |
| Ethernet Isolation | 1.5 kV RMS |
| Relative Humidity | 0% to 95% (non-condensing) at 25°C/77℉ |
