Exploring beyond Xovis?
Milesight Leads the Way

Install Range

Up to 3.5m

Standard Version: Up to 3.5m
High Ceiling Mount: Up to 6.5m

2.2m-6m

Standard Version: 2.5m~4m
High Ceiling Mount: 5m~7m

2.5~3m

Wall Mount: 0.7~1.2m (Optimal)

Ceiling Mount: ≤3m
Wall Mount: 1.2~1.3m（Optimal）

Detection Distance

4m×3m (Under the condition a 3.5m installation height and a 1.7m object height）
98 ° H, 80 ° V

Standard Version: 4.14m x 3.02m, installed at a height of 3.5m
98° H, 80° V
High Ceiling Mount: 5.54m x 3.98m, installed at a height of 6.5m
60° H, 45° V

FoV: 101° H, 70° V Detection Area: Range from 1.21m × 0.7m at the installation height of 2.2m to 10.44m × 6.02m at a installation height of 6m

Standard Version: 4.8m x 14m, intalled at a height of 3m 190 ° H, 112 ° V High Ceiling Mount: 5.5m x 14m, installed at a height of 7m 129.4 ° H, 68.4 ° V

5.55m×2.30m at a Installation Height of 3m

1.2~3m distance between the transmitter and the receiver

Ceiling Mount: Passage Width 2.8m, installed at a height of 3m
Wall Mount: Passage Width <2.3m
PIR: 50° H（3m Height, 2.8m Detecting Width）
Temperature: -30~70°
* The detection range decreases as the temperature rises.

Radar Sensor

/

√

/

/

√（battery only）

/

/

3-Axis Sensor

/

√

√

/

/

/

/

Temperature

/

/

/

/

√

/

√

LoRaWAN®

√

√

/

√

√

√

√

Ethernet (PoE)

√

√

√

√

/

/

/

Cellular

/

√

√

/

/

/

/

Wi-Fi HaLow

/

√

/

/

/

/

/

Wi-Fi

/

√

√

√ * Only VS121 (LoRa) Support

/

/

DI/DO

√ * VS133 (PoE) Only

√ * VS135 (PoE) Only

√

√ * VS121 (PoE) Only

/

/

Serial Port

√ * 1 × RS485 (VS133 (PoE) Only)

/

√

√ * 1 × RS485 (VS121 (PoE) Only)

/

/

Button

VS133 (PoE): 1 × Reset

1 × Reset/Wi-Fi Button

1 × Reset/Wi-Fi Button

VS121 (LoRa): 1 × Wi-Fi + 1 × Reset
VS121 (PoE): 1 × Reset

1 × Reset Button (Internal)

1 × Multi-function Button (Transmitter/Receiver) 1 × Reset (Internal, Transmitter)

1 × Reset

LED Indicator

√

√

√

√

√(Internal)

√

√(Internal)

Configuration

VS133 (PoE): Ethernet

VS135 (LoRa): Wi-Fi VS135 (PoE): Ethernet+Wi-Fi VS135(Wi-Fi HaLow): Wi-Fi VS135(Celluar):Wi-F

VS125 (Cellular): Wi-Fi
VS125 (PoE): Ethernet & WiFi

VS121 (LoRa): Wi-Fi
VS121 (PoE): Ethernet

NFC

NFC

NFC

Data Storage

1000000 sets

1000000 sets

1000000 sets

/

1,000 sets

1,000 sets

1,000 sets

Data Retransmission

VS133 (PoE) Support

Except VS135 (LoRa)

√

√

√

√

√

Milesight D2D

/

/

/

VS121 (LoRa) Support

√

√

√

Milesight IoT Cloud Management

/

√ * VS135 (LoRa) Only

/

VS121 (LoRa) Support

√

/

√

DeviceHub Management

VS133 (PoE) Support

√ * For VS135 (Celluar, Wi-Fi HaLow, PoE)

√

VS121 (PoE) Support

/

/

/

Milesight Development Platform

√

√

√

√

√

√

√

Power Supply

VS133: 12V/2A by DC Jack Connector
VS133 (PoE): 802.3at PoE+

VS135 (PoE): 802.3at PoE+ or DC 12V/2A
VS135 (Celluar/Wi-Fi Halow/LoRa) : DC 12V/2A

VS125 (PoE): 802.3af PD or DC 12V/1A
VS125 (Celluar): DC 12V/1A

VS121 (LoRa): 5V/1.5A by USB
VS121 (PoE): 802.3af PoE or 5V/2A by Terminal Block

Batteries or Type-C Port

4 × 2700 mAh ER14505 Li-SoCl2 Batteries (2 for each device)

2 × 2700 mAh Li-SOCL₂ Batteries

Dimensions

180 × 26 × 72 mm

200 x 35 x 85 mm

185 x 85 x 34 mm

VS121 (LoRa): 85 × 85 × 20 mm
VS121 (PoE): 85 × 85 × 30 mm

Type-C Version: 70 x 68 x 32 mm
Battery Version: 188 x 68 x 32 mm

76 x 62 x 20 mm

100 x 70 x 21 mm

Operating Temperature

-20°C~50°C

-20°C~50°C

-20°C~50°C

-5°C~55°C

-20°C ~ 60°C

-20°C ~ 50°C

-20°C~60°C

Installation

Standard Version: 2.5m~4m
High Ceiling Mount: 5m~7m

Ceiling Mount: 2.5m~3m
Wall Mount: Prevent Obstruction of ToF

VS340: 0~50cm from the Table Edge
VS341: 0~40cm from the Table Edge
Optimal Distance: 20~40cm

Range:2.3m~3m

2.4m~4m

Maximum 8m

2m

Detection Range

Standard Version: 4.8m x 14m, intalled at a height of 3m
190 ° H, 112 ° V
High Ceiling Mount: 5.5m x 14m,intalled at a height of 7m
129.4 ° H, 68.4 ° V

0.04m~3.5m
PIR: 80 °
ToF: 27 °

PIR Detecting Range: 107° H, 107° V（No PIR Covers）
107 ° H, 107 ° V
PIR Detecting Range: Maimum 1m
50°

Radar Detection Distance Movement: 7.5m Slight Movement: 4.8m PIR Detection Distance Within 7m

129 ° H, 93 ° V

Maximum 8m
120 ° H, 100 ° V

PIR Detection Distance: Maximum 6 m

LoRaWAN®

√

√

√

√

√

√

√

Ethernet (PoE)

√

/

/

/

/

/

/

Wi-Fi

VS121 (LoRa) Support

/

/

/

/

/

/

DI/DO

1/1 (VS121 (PoE) Only)

/

/

/

/

/

/

Serial Port

1 × RS485 (VS121 (PoE) Only)

/

/

/

/

/

/

Button

VS121 (LoRa): 1 × Wi-Fi + 1 × Reset VS121 (PoE): 1 × Reset

1 × Power/Reset

1 × Power/Reset

1 × Reset Button

1 × Multi-function Button

/

1 x Power/Reset Button (Internal)

LED Indicator

√

√

√

/

√

/

√

Configuration

VS121 (LoRa) : Wi-Fi VS121 (PoE): Ethernet

NFC

NFC

NFC & Bluetooth

Bluetooth

NFC

NFC

Milesight D2D

VS121 (LoRa) Support

/

√

√

√

√

√

Milesight IoT Cloud Management

VS121 (LoRa) Support

√

√

/

/

√

√

DeviceHub Management

VS121 (PoE) Support

/

/

/

/

/

/

Power Supply

VS121 (LoRa) : 5V/1.5A by USB
VS121 (PoE): 802.3af PoE or 5V/2A by Terminal Block

3 × 4000 mAh Li-SOCL₂ Batteries

1 × 4000 mAh Li-SOCL₂ Battery

2 × 2700 mAh ER14505 Li-SOCL₂ Batteries

4 × 2700 mAh ER14505 Li-SOCL₂ Batteries

1 × 1650 mAh ER14335 Li-SOCL₂ Battery

1 × 4000 mAh ER18505 Li-SOCL₂ Battery

Dimensions

VS121 (LoRa): 85 × 85 × 20 mm VS121 (PoE): 85 × 85 × 30 mm

Ф100 x 24 mm

73 x 73 x 26 mm

Ф 70 × 48.5 mm (Ф 2.76 × 1.91 in)

100 × 100 × 26 mm (3.94 × 3.94 × 1.02 in)

50 × 50 × 23.8 mm

73 x 73 x 26 mm ( 2.87 x 2.87 x 1.02in) (Without PIR Cover)

Operating Temperature

-5°C~55°C

-20°C~60°C

-20°C~60°C

0°C ~ 30°C

0°C ~ +30°C

20°C ~60°C

-20°C to +60°C
